PECO Monolock

A study bracket of cast iron with foundation holes carries the pump volute casing at one end and flagged.

PECO-Newman motor on the other end. Pump and motor shaft are an integral part. The shaft is protected against against wear and corrosion by a stainless steel sleeves. This type is lighter and requires less space than PCF model, but is equally sturdy and dependable. Motors are flanged squirrel cage type, 4 pole and AC 400 3/5 with nominal speed of 1460 RPM.
